- Digital wide spectrum in 748 ~ 938 MHz, by country/region
- Noise-free technology improves audio tour experience
- High-contrast OLED screen for easy viewing, even users with low vision
- 5/25/50-slot chargers at option to suit best tour type
- Programmable display for perfect fit on specific application (w/ proprietary software OK-OTG-SW)
- 2 x AA battery (NiMH, Alkaline) for 18+ hour run time
|
TRANSMITTER
|
OTG-200T
|
|
Emission modulation
|
GFSK
|
|
Carrier frequency range
|
748 MHz ~ 938 MHz (region dependent)
|
|
Channels
|
Various upon countries
|
|
Microphone type
|
Electrical condenser
|
|
RF output power
|
Hi: 13 dBm
Low: 10 dBm (region dependent)
|
|
Operation range
|
> 100 meters (open field @ Hi power)
|
|
Power requirements
|
2 x AA type 1.5V Alkaline batteries or
2 x AA type 1.2V Ni-MH rechargeable batteries
|
|
Charging time
|
4 ~ 6 hours @ 1.2V / 1,600 mAh Ni-MH rechargeable batteries
|
|
Battery life
|
16 ~ 18 hours @ 2,100 mAh (Alkaline)
|
|
Dimensions (H x W x D)
|
95 x 46.5 x 32 mm (with belt clip, without antenna)
|
|
Weight
|
55 ± 5 g without batteries
|
|
RECEIVER
|
OTG-200R
|
|
RF output power
|
10 dBm
|
|
Earphone / Earphone Mic
|
3.5 mm
|
|
Dimensions (H x W x D)
|
95 x 46.5 x 32 mm (with belt clip, without antenna)
|
|
Weight (with battery)
|
55 ± 5 g without batteries
|
|
|
|
